Blackhawk II (E1658-10)

Floor Plan Details

• Total Bedrooms:
• 4
• # of Bedrooms on Main Floor:
• 3
• Bathrooms:
• 3
• Main Floor Sq Ft:
• 1471
• Basement Sq Ft:
• 807
• House Width (Ft):
• 49
• House Depth (Ft):
• 36

Room Details

• Great Room:
• 14'-0 x 16'-0 Main
• Kitchen:
• 15'-0 x 14'-2 Main
• Dining Room:
• 10'-0 x 11'-8 Main
• Living Room:
• 1 Main
• Family Room:
• 14'-0 x 12'-10 Basement
• Laundry:
• 8'-4 x 7'-4 Main
• Utility / Storage Room:
• 9'-6 x 6'-10 Basement
• Deck / Patio 1:
• 9'-8 x 7'-8
• Master Bedroom:
• 13'-4 x 14'-8 Main
• Bedroom 2:
• 10'-6 x 11'-0 Main
• Bedroom 3:
• 10'-6 x 11'-0 Main
• Bedroom 4:
• 11'-0 x 11'-2 Basement
• All Bedrooms Have A Bathroom:
• No
• Master Bathroom:
• 8'-4 x 9'-4 Main
• Bathroom 2:
• 8'-4 x5'-0 Main
• Bathroom 3:
• 8'-2 x5'-0 Basement

Kitchen Options

• Eating Bar:
• Yes
• Open Plan:
• Yes
• Nook:
• Yes

Living Style Options

• Great Room Concept / Open Plan:
• Yes

Interior Details

• Great Living Room Fireplace:
• Yes
• Steam Room:
• No
• Skylight(s):
• No
• Hot Tub:
• No
• Sauna:
• No

Master Bedroom Options

• Pieces In Ensuite:
• 4

Garage Options

• Garage Size:
• 23'-6 x 29'-10
• Number of Vehicles:
• 2
• Front Load:
• Yes
• Workspace:
• Yes
• Garage Left/Right:
• Left

Ceiling Options

• Main Floor Ceiling Height:
• 9
• Basement Ceiling Height:
• 9

Lot Details

• View To Street Side:
• Yes
• Lot Sloping Upwards From Street:
• Yes

Construction Details

• Framing Lumber:
• 2x6
• Framing:
• Concrete Post & Beam Construction
• Roof:
• Asphalt
• Foundation:
• Slab on grade
• Wall Finish:
• Siding
• Wall Finish:
• Stone

Plan Permit Info

Plan Costs

• Planbook 5 Print Sets 24x36 - ¼" Scale Copies:
• $1,250.00

• Planbook 8 Print Sets 24x36 - ¼" Scale Copies:
• $1,500.00

• Planbook purchase with PDF's:
• $1,750.00
• Extra 24x36 ¼" Scale Copies:
• $65.00
• Reverse Plan:
• $300.00
• Colour Rendering:
• $150.00
• 11" x 17" - 1/8" Scale Copy:
• $25.00
• Shipping within B.C.
• $29.95
• Shipping within Canada:
• $50.00
• Shipping to USA:
• Please Ask For Quote
• Shipping outside of North America:
• Please Ask For Quote
• Shipping Mounted Renderings:
• Please Ask For Quote
